产品简介

IO Industries高速相机 12M180 12M125 4KSDI 4M140 4M1802KSDI 2M280 2M360Victorem

公司简介

深圳市金通方略科技发展有限公司是一家国际知名品牌代理商。公司立足中国改革开放的窗口深圳，毗邻香港，面向世界。主要产品有摄像机，监视器，镜头，红外芯片，数字一体化系统方案等。涉及行业有医疗器械，医疗示教，视频会议，机器视觉，远程教学，高端监控，冷热红外WX技术等领域。经营品牌有东芝，索尼，日立，松下，富士能，图丽，IMPERX，BASLER，JAI，MATROX，Princeton Instruments，UNIQ，e2v，Foresight Imaging，PLEORA等。
根据市场需求共设五个部门：视频传播部、医疗设备部、机器视觉部、安防监控部及工程部。
　深圳市金通方略科技发展有限公司汇聚一批高素质人才，同心同德，力创未来。追求精湛，灵活变通，四方来客，供图谋略。我们重人才，重市场，重科学，重团队，重合作。
金通方略公司以务实创新，诚信立本，公平建制,共赢共利，平等合作的企业理念，与供应商及客户建立了良好的合作关系，全力打造行业先行者。为客户提供精确的产品，精准的方案，周到的服务。感谢您的光临和支持！

展开

产品说明

IO Industries高速相机 12M180 12M125 4KSDI4M140 4M1802KSDI 2M280 2M360Victorem

2KSDI—Flare系列 12M180， 2M280-CXP，2M360-CL，4M180-CL，4M140-CXP，12M125-L

Flare系列高速相机采用了2款高速CMOS芯片制作而成，所以其分辨率有200万像素及400万像素可供选择，其数据接口也分为了Cameralink接口以及CXP接口，可以广泛应用于高速运动物体的跟踪拍摄，以及可以提供中数据距离传输的解决方法。
2KSDI 12M180
Multi-Faceted Mini-cam 12M180
The 2KSDI is built to be completely flexible, yet small enough to fit into a range of specialty applications for both broadcast and cinema. The camera is built on IO Industries' years of experience with industrial cameras, yet packs in the flexible color processing and optics support required by video professionals.

Small Size, Huge Potential
Weighing in at 310g, the 2KSDI is no larger than an average apple. With its' solid aluminum housing and flexible lensing options, the 2KSDI quickly becomes known as "the tough little camera that could" on most shoots. Though some professional mini-cams require a separate camera control unit, all of the 2KSDI's functions can be set directly on the camera head.

So Many Modes!
The 2KSDI can travel where other cameras can't, yet it can also speak the language when it gets there. The camera can be configured in full 2K RAW for digitial cinema one day, then 422 interlaced for live broadcast the next. All of this is configured from an easy to use on-screen display with the small handheld remote, or by attaching an RS485 cable for long distance control.

Camera Features
Sensor Size (H x V)	2048 x 1088 pixels
Maximum frame Rate	60fps at 1080p
Sensor Details	60dB CMOS, 5.5 µm pixels (12.7mm diagonal)
Shutter	Pipelined global shutter with correlated double sampling
Image Type	4:2:2(Y'Cb'Cr'), or RAW (Bayer)
Pixel Format	10-bit
Video Interface	3G/HD-SDI, both clean feed and OSD feed
White Balance	Automatic (AWB), tracking AWB, or manually adjustable
Color Adjustment	Color matrix, saturation
Black/White Adjustment	Master pedestal, black gamma, knee point
Camera Control	RS-485, handheld remote or PC control, up to 1000ft
Synchronization	External tri-level sync input
Exposure Control	Automatic (AEC) or manually adjustable in 1/8-degree steps

Output Modes
Single link HD-SDI	• 720p 10-bit (4:2:2 or RAW): 23.98/24/25/29.97/30/50/59.94/60 • 1080i 10-bit (4:2:2 or RAW): 50/59.94/60 • 1080p 10-bit (4:2:2 or RAW): 23.98/24/25/29.97/30 • 2K 10-bit (4:2:2 or RAW): 23.98/24/25/29.97/30
Single link 3G-SDI	• 1080p 10-bit (4:2:2 or RAW): 50/59.94/60 • 2K x 1080p 10-bit (4:2:2 or RAW): 50/59.94/60

Specifications
Housing Size	63.5 x 63.5 x 44.1mm
Ambient Temperature	Up to 50°C
Lens Mount	Native C-Mount or T-Mount
Ports	(2) SDI, (1) SYNC-IN, (1) 12-pin Hirose
Power Requirements	12 VDC (via Hirose)
Power Consumption	4.5 Watts
Weight	310 grams
