41183 BURKERT电磁阀41183型参数@BURKERT东莞代理

BURKERT电磁阀41 为直动式、介质隔离的转动衔铁电磁阀。两位两通和两位三通式。两位三通式可用作分配阀或混合阀。根据不同的应用，可以选择各种膜片材质和工作方式。标准供货的黄铜阀体符合所有欧洲饮用水标准的要求。

东莞宸越工业设备有限公司是日本SMC、德国FESTO费斯托、德国宝德BURKERT、日本喜开理CKD、日本KOGANEI小金井一级代理商.
主营产品有日本SMC气缸,SMC薄型气缸,日本SMC电磁阀,德国FESTO电磁阀,德国FESTO气缸,德国BURKERT电磁阀,德国BURKERT角座阀,BURKERT流量计,BURKERT变送器等BURKERT产品.CKD电磁阀,CKD气缸,CKD气动元件.KOGANEI电磁阀,KOGANEI气缸,KOGANEI气动元件等.欢迎各界朋友莅临东莞市宸越工业设备有限公司参观、指导和业务洽谈。

联系人：王荫
电  话：0769-33319812
Q  Q：2720653032
邮  箱：2720653032@qq.com
地址：东莞市南城区莞太路12号中兴大厦510室

BURKERT电磁阀41183型参数@BURKERT东莞代理

BURKERT电磁阀41183型0331 为直动式、介质隔离的转动衔铁电磁阀。两位两通和两位三通式。两位三通式可用作分配阀或混合阀。根据不同的应用，可以选择各种膜片材质和工作方式。标准供货的黄铜阀体符合所有欧洲饮用水标准的要求。阀体材质还有不锈钢（316L)、PVDF 和聚丙烯。电磁线圈采用耐化学腐蚀的环氧树脂封装。0331型配备了手动开关，可用于调试和测试。如有节能要求，所有线圈都可提供节电式，或脉冲式。开关状态可以通过位置反馈以二进制或 NAMUR 信号显示。与 DIN EN 17301-803 A 型电缆插头配套，该阀的安全防护等级为 IP65/67，不锈钢或塑料阀体式 NEMA 4X。

BURKERT电磁阀41183型参数@BURKERT东莞代理
Type 0331
Operation direct-acting
Actuator type Pivot
Main valve operating principle Globe valve
Switch function on/off
Media separation Yes
Valve function C - normally inlet port 1 (P/NC) closed, outlet port 2 (A/OUT) conectedwith exhaust port 3 (R/NO)
Fluidic port connection number 3
Valve function number of switching positions 2
Valve function manual actuation Yes
Valve function manual actuation type Key button
Valve function manual actuation material PA (Polyamide)
Valve function manual actuation stop Yes
Flow Below seat
Nominal pressure min 0 bar
Nominal pressure max (liquid) 16 bar
Main valve orifice 1 (P) (mm) 2 mm
Main valve orifice 3 (R) (mm) 2 mm
Kv value (water) 0.08 m3/h
Main valve wetted material Brass
Port connection 1 type Flanged

BURKERT电磁阀41183型参数@BURKERT东莞代理

Port connection 1 flange Bürkert flange 32 x 46 version A2
Port connection 2 type Flanged
Port connection 2 flange Bürkert flange 32 x 46 version A2
Port connection 3 type Flanged
Port connection 3 flange Bürkert flange 32 x 46 version A2
Valve seat material Brass
Seat seal material NBR (Nitrile rubber)
Seat seal material Shore hardness 70
Sealing toward outside material NBR (Nitrile rubber)
Temperature environment max 55 °C
Temperature medium min 0 °C
Temperature medium max 80 °C
Temperature surface max 155 °C
Voltage / rated voltage 24 V
Voltage / rated voltage 24 V
Voltage tolerance negative 10 %
Voltage tolerance positive 10 %
AC voltage No
DC voltage Yes
Battery voltage Yes
Rated power DC 11 W
Reduced power DC 11 W
Rated power consumption 8 W
Electrical connection sort Plug pattern form A according to DIN EN 175301-803
Electrical connection number of contacts 2 + Grounding conductor
Cable plug in delivery enclosed
Cable plug art. no. - type 00008376 - 2508
Electrical connection position top
Electrical connection polarity Irrelevant
Electrical connection material Brass
Protection type (IP max. with suitable connector) 65
Coil type block bolted
Coil insulation material (encasement) Epoxy
Coil wiring overvoltage protection without
Coil wiring rectifier No
Coil wiring polarity protection No
Coil wiring polarity recovery diode No
Thermal insulation class of the actuator H
Nominal operation/Duty cycle 100 %
Switch time open min 10 ms
Switch time open max. 20 ms
Switch time close min 10 ms
Switch time close max. 20 ms
Valve setting opening time No
Valve setting closing time No
Back-pressure-resistant version No
Vacuum version No
Analysis version No
Oil burner valve No
Steam version No
Low-noise version No
Main valve with integrated screen No
Installation length 46 mm
Without mounting No
Valve construction Valve complete
Weight 0,456000 kg
Weight 0,456000 kg

BURKERT电磁阀41183型参数@BURKERT东莞代理
