价格：电议
所在地：江苏 盐城市
型号：
更新时间：2017-07-12
浏览次数：1314
公司地址：江苏省盐城市亭湖区新园路50号1幢
杨(先生) 经理
Ø 全自动转子识别系统
Ø 高力矩变频无刷电机
Ø 微机控制，触摸面板，液晶显示
Ø 进口压缩机组，环保型制冷剂，启动即可进行预冷
Ø 设有不平衡、超速、电子门锁,皮带等多重保护，确保人机安全
Ø 运行中离心力和转速可随时更改和查看，断电参数可自动储存
Ø 0-9档10种升降程序和多种自定义工作模式，客户可按需求选择
2 Automatic rotor identification system
2 The brushless direct drive motor with high start torque and frequency inversion
2 Controlled by microcomputer with touching panel and LED display
2 The compressor operating without Freon for environment protection, pre-cooling when power on
2 The function of imbalance, over-speed, electronic lock lid, strap for protection
2 Setting or changing the RCF and speed during the operation, automatically storing the parameter
2 Adjustable rise-and-fail speed from grade 0 to 9 with kinds of self-defining models
技术参数TECHNICAL PARAMETER
|
型号 Model |
AXGL21M |
|
zui高转速 Max Speed |
21000r/min |
|
zui大相对离心力Max RCF |
48900×g |
|
zui大容量 Max Capacity |
3000ml |
|
转速精度 Speed Accuracy |
±20r/min |
|
温控范围 Temperature Range |
-20℃--40℃ |
|
温控精度 Temperature Accuracy |
±1℃ |
|
定时范围 Time Range |
0-99H59min |
|
电源 Power Supply |
AC 220V 50Hz 3 |
|
整机噪声 Noise |
≤65dB |
|
外形尺寸 Dimension |
810×710×1220mm |
|
重量 Weight |
320kg |
转子Rotor
|
转子类型 Model |
转子编号 Number |
容量 Capacity |
zui高转速 Max Speed |
zui大相对离心力 Max RCF |
|
No.1 |
16×10ml |
21000 |
48900 |
|
|
No.2 |
16×1.5ml |
21000 |
48900 |
|
|
No.3 |
6×50ml |
20000 |
43000 |
|
|
No.4 |
8×100ml |
12000 |
19830 |
|
|
No.5 |
4×300ml |
11000 |
19300 |
|
|
No.6 |
6×300ml |
10000 |
18500 |
|
|
No.7 |
6×500ml |
8000 |
11680 |
|
|
水平转子 Swing Rotor |
No.8 |
4×50ml |
5000 |
4390 |
|
No.9 |
8×50ml |
4000 |
2950 |
|
|
No.10 |
32×15ml |
4000 |
3160 |
|
|
No.11 |
4×500ml |
5000 |
5470 |
|
|
连续流转子 Continuous Rotor |
No.12 |
1000ml |
14000 |
21500 |
|
No.13 |
3000ml |
8000 |
9500 |
|
|
酶标转子 Bucket Rotor |
No.14 |
2×2×96孔 |
4000 |
2300 |
|
间歇转子 Lntermittent Rotor |
No.15 |
1000ml |
17000 |
31390 |
|
No.16 |
2000ml |
12000 |
19350 |
|
|
No.17 |
4400ml |
8000 |
14890 |
免责声明：以上所展示的[ AXGL21M落地式高速冷冻离心机]信息由会员[盐城市安信实验仪器有限公司]自行提供，内容的真实性、准确性和合法性由发布会员负责。
