进口宝德电磁阀参数：
Solenoid Valve for neutral media and steam up to 180 °C
Type 0355 / 商品编号 49025
Type 0355
Operation direct-acting
Actuator type Plunger valve
Main valve operating principle Globe valve
Switch function on/off
Media separation No
Valve function C - normally inlet port 1 (P/NC) closed, outlet port 2 (A/OUT) co
nectedwith exhaust port 3 (R/NO)
Fluidic port co
nnection number 3
Valve function number of switching positions 2
Valve function manual actuation No
Flow Above seat
Nominal pressure min 0 bar
Nominal pressure max (liquid) 14 bar
Main valve orifice 1 (P) (mm) 2 mm
Kv value (water) 0.11 m3/h
QNn value (gas) 100 l/min
Main valve wetted material Brass
Port co
nnection 1 type Inner thread
Port co
nnection 1 thread type G
Port co
nnection 1 thread marking 1/4
Port co
nnection 2 type Inner thread
Port co
nnection 2 thread type G
Port co
nnection 2 thread marking 1/4
Port co
nnection 3 type Outer thread
Port co
nnection 3 thread type M
批发进口宝德电磁阀@Burkert产品快速报价
Port co
nnection 3 thread marking 14 x 1,5
Valve seat material Stainless steel
Medium-co
ntacting part core material Stainless steel
Medium-co
ntacting part stopper material Stainless steel
Seat seal material PTFE (Polytetrafluorethylene)
Sealing toward outside material Brass and stainless steel
Temperature enviro
nment min -40 °C
Temperature enviro
nment max 55 °C
Temperature medium min -40 °C
Temperature medium max 180 °C
Voltage / rated voltage 230 V
Voltage / rated voltage 230 V
Voltage tolerance negative 10 %
Voltage tolerance positive 10 %
Voltage frequency 50 Hz
AC voltage Yes
DC voltage No
Battery voltage No
Rated power co
nsumption 10 W
Electrical co
nnection sort Plug pattern form A according to DIN EN 175301-803
Electrical co
nnection number of co
ntacts 2 + Grounding co
nductor
Cable plug in delivery enclosed
Cable plug art. no. - type 00131874 - 2508
Electrical co
nnection position in direction of flow left
Protection type (IP max. with suitable connector) 65
Coil type placed on top
Coil insulation material (encasement) Epoxy
Coil size 40 mm
Coil wiring overvoltage protection without
Coil wiring rectifier No
Coil wiring polarity recovery diode No
Thermal insulation class of the actuator H
Nominal operation/Duty cycle 100 %
Switch time open min 10 ms
Switch time open max. 20 ms
Switch time close min 20 ms
Switch time close max. 30 ms
Valve setting opening time No
Valve setting closing time No
Back-pressure-resistant version No
Vacuum version Yes
Analysis version No
Oil burner valve No
Steam version Yes
Low-noise version No
Main valve with integrated screen No
Without mounting Yes
Valve co
nstruction Valve complete
Weight 0,680000 kg
Weight 0,680000 kg
批发进口宝德电磁阀@Burkert产品快速报价
顾诚说过：“黑夜给了我黑色的眼睛就是为了让我寻找光明”公司给了您这边采购的权利，您这边寻找的不就是我们这边的气动品牌元件，我们专业销售日本SMC,德国FESTO，德国BURKERT,日本CKD,美国ASCO等等气动元件产品，全新原装进口，价格好，货期有！：萧小姐，：0
批发进口宝德电磁阀@Burkert产品快速报价
025558V0305-C-01,2-BB-MS-GM82-110/56-05
025580Q0290-A-12,0-BB-MS-0000-230/50-10
025587B0311-C-01,5-NN-VA-GM81-240/60-08
025614M0681-A-13,0-BB-MS-GM84-230/UC-07
025619S0281-B-20,0-AA-MS-GM85-230/56-08
025626R0256-A-05,0-NA-MS-GM83-024/UC-CB
025662V0404-B-12,0-BB-MS-GM84-230/50-08
025672X0280-A-13,0-AA-MS-GM84-230/50-08
025675S0406-A-25,0-EG-MS-GM86-220/60-08
025676T0280-A-08,0-AA-MS-GM83-024/50-08
025677U0211-A-00,0-FF-MS-0000-230/50-08
025691K0301-C-01,2-BB-MS-FK01-024/56-04
025720T0124-F-04,0-FF-PD-GM82-024/DC-08
025732K0301-D-01,2-BB-PA-FK01-024/DC-04
025746Z0211-A-00,0-FF-MS-0000-024/DC-08
025747S0243-A-06,0-BB-MS-GM83-230/56-14
025769G0312-C-02,0-BB-MS-0000-024/50-02
025790S0355-C-03,0-BF-MS-GM82-110/50-10
025815F0641-A-02,0-BB-MS-GM82-230/UC-07
025816G0355-C-02,0-FF-MS-GM82-230/50-10
025820Q0311-D-02,0-AA-MS-GM81-024/50-08
